SIGNERS SUPiA Dry Thermal X-ray Film Printer
SP3000+ is a dry printer designed
to output information processed through
DICOM image printing.
SP3000+ supports 4 film sizes.
8”x10”, 10”x12”,
11”x14” and 14”x17”
Achieve the convenience of
multiple sizes.
SP3000+ boasts high quality X-ray images
when used with SUPiA gram
SP3000+ Specifications
Print Technology:
Direct thermal printer
(dry, daylight-load film)
Spatial Resolution 320dpi (12.6 pixels/mm)
Throughput:
14”x17” >= 50 sheets/h
8”x10” >= 70 sheets/h
Grayscale Contrast
Resolution: 14 bits
Film Transferring
Method: Rubbing
Film Tray: Two supply tray, 200-sheet
capacity total
Film Sizes: 8”x10”, 10”x12”, 11”x14”, 14”x17”
Applicable film: Medical Dray Thermal Film(blue or clear base)
Interface :10/100/1000 Base-T Ethernet(RJ-45)
Network Protocol: Standard DICOM 3.0
connection
Image Quality: Automatic calibration
Using built-in densitometer
Control Panel: Touch Screen, Online Display, Alert, Fault and Active
Power Supply 100-240VAC 50/60Hz 600W
Weight: 50Kg
Operating Temperature: 5°C-35°C
Storage Humidity :30%-85%
Storage Temperature: -22°C-50°C
Base Holding :Optional
